Electrical Installation for Technical Secondary Schools – Full Notes
Click the links below to view the notes:
FORM FOUR
..
..
In electrical terminology, this alarm system is called a closed-circuit system. When the doors and windows are shut, the attached switches are closed. Because all the switches are in a wiring loop, opening any one of them breaks the loop and triggers the sounder circuit. Simply closing the door or window, moreover, does not restore the switch loop circuit continuity and does not stop the sound until either the battery becomes exhausted or someone switches off the circuit from battery to sounder.
There is an electronic switch built into the sounder. This switch is turned on by breaking the magnetic-switch loop. A key-operated switch in the sounder circuit allows you to turn the alarm system completely off when it is not needed. Also, once the alarm goes on, operating the key switch is the only way to silence the sounder. Only someone who has a key to the switch can reset the system.
Direct Current (DC) flows continuously in a single direction. It is the standard for battery-powered devices, modern electronics, and low-voltage wiring. For instance, if you are planning a low-voltage project, understanding how low-voltage DC systems are integrated into modern commercial properties is essential for data and network stability.
Alternating Current (AC) constantly reverses its direction, usually 50 or 60 times per second (Hertz/Hz).
Single Phase AC uses two wires (a live/hot phase and a neutral). It is the standard supply brought into residential homes.
Three Phase AC uses three separate active phases, offset in time. This provides continuous, highly efficient power delivery without the “pulsing” nature of single-phase systems, making it perfect for running heavy industrial motors.
Voltage supplies must remain within strict, legally permitted tolerances to prevent damage to equipment. For example, the permitted voltage tolerance for UK supplies is 10% of the declared nominal voltage, giving a safe working range of 216V to 253V for a nominal 230V supply.
In commercial settings, managing these different phases and voltage demands requires highly structured planning. You can read more about how commercial systems are balanced in The Complete Guide to Commercial Wiring.
